To solve this, RIGHT CLICK on the port allotted inside Device Manager & select PROPERTIES. Only in ON LINE Mode you can load the HEX file. If the port allotted is a double digit, then WLPRO will enter DEMO mode. If the PORT allotted is within range 1 to 9, you can start the WLPRO application and proceed to load HEX file.
Unzip the driver file & double click on “PL2303_Prolific_DriverInstaller_v1.10.0 “ EXE file to install the drivers.Ĭonnect the USB cable of board to PC & open the DEVICE MANAGER. No installation is required.It is a standalone application.ĭownload the drivers required for this board from : WILPRO’s WLAR software is used as an application to fuse the HEX files.Download the zip file from : Put the jumper (found on top of I2C EEPROM IC) on 8051 position. Select the ISP switch (switch 2 near the middle of board) to ON position.This makes sure that you’re going to program the chip. If this switch is selected to other side, the board needs an external 12v/1A adapter. Select switch 1 to USB position ,if you connect the board to PC using A to B USB cable.Now the power is taken from USB itself. To start with we shall see how to use this board for 8051 development. Additional 40 pin ZIF socket with modified connection is provided to host AVR ICs.This additional ZIF socket should be placed over the on- board ZIF socket to use AVR ICs. First time in India, VEGA ROBOKITS has engineered a development board universal to both AVR & 8051 ICs.The board has in built Programmer capable of programming both AVR & 8051 family ICs.Ī 40 pin ZIF socket is used as Target to hold the 8051 IC.
